Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature

Product Categories

Henan Swet Boiler Co., Ltd.

Contact Now

Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature

Name: Quick Loading Circulating Fluidized Bed Boiler 104 Feed Water Temperature
Brand: SWET
Price: 250000 USD

Brand Name : SWET

Model Number : DHX30-2.5/400-0019

Certification : ISO9001

Place of Origin : Henan China

MOQ : 1 Set/Sets

Price : USD 250000 - 300000 Set/Sets

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement

Supply Ability : 700 Set/Sets Per Year

Delivery Time : shipped in 60 after payment

Packaging Details : 1. Industrial Steam Boiler in nude package. 2. All boiler accessories in plywood or wooden case. 3.Delivery Detail :Shipped in 60 days after payment

Rated evaporation : 30t/h

Work pressure : 2.5MPa

Steam temperature : 400℃

Feed water temperature : 104℃

Dimensions : 12170x9200x25500mm

Thermal efficiency : 91%

Contact Now

30 Tons Quick Loading Vertical Full Automatic Circulating Fluidized Bed Boiler For Power Plants

Product description

1. Circulating fluidized bed is of low-temperature combustion, therefore, nitrogen oxides emissions of such boiler is much lower than that of coal-powder boiler, and such boiler could directly desulfurized during combustion process.

2. Circulating fluidized bed boiler with high desulfurization rate is economical.

3. Circulating fluidized bed boiler could adopt various coal types and has high combustion efficiency, which is especially suitable for low quality, low calorific value coal.

Benefits

1. Greatest Fuel Flexibility

2. Best overall solution for high moisture fuels.

3. Ability to burn fuels containing mid-level amounts of alkali.

4. Proficient at combusting fuels from the extreme low-end to extreme high-end moisture contents.

Circular flow bed CFB boiler technical parameters

Model	Rated evaporation	Work pressure	Steam temperature	Water supply temperature	Fuel consumption	Thermal efficiency	Dimensions
Unit	t/h	MPa	℃	℃	Kg/h	%	mm(Long x wide x high)
DHX20-1.25	20	1.25	194	104	2475	91	12000x8160x22120
DHX20-1.6	20	1.6	204	104	2483	91	12000x8160x22120
DHX20-2.5/400	20	2.5	400	104	2934	91	12000x8160x22120
DHX25-1.25	25	1.25	154	104	3003	91	13000x8610x23170
DHX25-1.6	25	1.6	204	104	3100	91	13000x8610x23170
DHX25-2.5/400	25	2.5	400	104	3692	93	13000x8610x23170
DHX30-1.25	30	1.25	194	104	3712	93	12170x9200x25500
DHX30-1.6	30	1.6	204	104	3724	93	12170x9200x25500
DHX30-2.5/400	30	2.5	400	104	4431	93	12170x9200x25500
DHX35-1.25	35	1.25	194	104	4331	91	13800x10320x26815

Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature

Product Tags:

circulating fluidized bed combustion boiler

coal power plant boiler

Quick Loading Circulating Fluidized Bed Boiler 104℃ Feed Water Temperature Images
